Characteristic:
There are two selections for this series, plain and reinforced specifications. Plain specifications are economic. Reinforced specifications contain fiber glass scrim, high tensile strength, easy to use and economic.
Application:
Used mainly in vapor barriers with various insulation materials. Also used for in-line lamination of glass wool, rock wool, and mineral wool. Flexible applications.
|
Product Series |
Construction |
Characteristic |
|
Foil:7μm / Polyethylene / Kraft. |
Foil-Kraft facing. Suitable for vapor barrier of HVAC ducts, without glass scrim. |
|
|
Foil:7μm / Polyethylene / 8*12/100cm2, 3-way scrim / Kraft. |
3-way Foil-scrim-Kraft facing. Suitable for duct wrap and metal building as well as pipe insulation. |
|
|
Foil:7μm / Flame-retardant adhesive / 8*12/100cm2, 3-way scrim / Flame-retardant Kraft. |
Flame-retardant 3-way Foil-scrim-Kraft facing. Suitable for duct wrap and metal building as well as pipe insulation. |
|
|
Foil:7μm / Polyethylene / 12.5*12.5mm, 2-way scrim / Kraft. |
2-way Foil-scrim-Kraft facing, balanced tensile strength in both lengthwise and crosswise directions. Suitable for duct wrap and metal building as well as pipe insulation. |
|
|
Foil:7μm / Polyethylene / 6.25*12.5mm, 2-way scrim / Kraft. |
Closer 2-way Foil-scrim-Kraft facing, balanced tensile strength in both lengthwise and crosswise directions. Suitable for duct wrap and metal building as well as pipe insulation. |
|
|
Foil:7μm / Flame-retardant adhesive /12.5*12.5mm, 2-way scrim / Flame-retardant Kraft. |
Flame-retardent 2-way Foil-scrim-Kraft facing, balanced tensile strength in both lengthwise and crosswise directions.Suitable for duct wrap and metal building as well as pipe insulation. |
|
|
Foil:7μm / Flame-retardent adhesive /6.25*12.5mm, 2-way scrim / Flame-retardent Kraft. |
Flame-retardent closer 2-way Foil-scrim-Kraft facing, balanced tensile strength in both lengthwise and crosswise directions. Suitable for duct wrap and metal building as well as pipe insulation. |
※ “**” in above products codes means the weight of Kraft，Standard Kraft weight: 50 gsm and 60 gsm. The foil thickness and Kraft weight can be custom-made.
※ Typical widths:1.20m, 1.25m and 1.30m. The length and width of the jumbo roll can be custom-made.
※ Please refer to data sheets for further technical information.
